GOOSENECK
20GT
Gooseneck | Tilt Deck Tandem Axle | Electric Brakes
20GT SPECS↓
GVWR 25,000 lbs
Capacity (Distributed) 18,160 lbs
Base Trailer Weight 6,840
Frame Construction 8" x 4" Tubular Subframe with High Tensile Perimeter Rails
Crossmembers 4" x 2” Tubular Crossmembers on 16” Centers
Hitch 2 - 5/16” Gooseneck Coupler, 25,000 lb Capacity
Landing Gear 12,000 lb Capacity with Drop Foot
Safety Chains Qty 2 - 3/8" x 36" Grade 70 High Tensile Strength with Slip Hooks and Safety Latches
Deck Latch Over-Center Type with Tension Adjuster and Safety Pin
Cushion Cylinder 4" x 16" with Metered Flow to Cushion Loading and Unloading
Load Securement 14 each (7 per side) 2-way Chain Slot/Stake Pocket System | 10 Each (5 per side) 1" Diameter D-Rings
Tool Compartment In Upper Gooseneck with Lockable Lid
Axles Qty 2 – 10,000 lb Capacity
Hubs Oil Bath Type, 8 on 6.5" Bolt Circle with 5/8” Lug Nuts
Brakes 12-1/4" x 3-1/2" Electric Brakes both Axles with 12 Volt Sealed Breakaway System
Suspension 3-Point Spring with Axle Alignment Capability
Wheels 16" x 6" 8 on 6.5" Bolt Pattern
Tires ST235/85R16 Radial Load Range E
Finished Preparation Sandblast
Finish Coating 1 Stage Zink Based Paint
Electrical Phillips Sealed Harness System with Rubber Isolated LED Lighting
Decking 2” Rough Surface No.1 Grade Fir: Exterior Boards Fastened at all Crossmembers
Decking Width 102”
20GTS
Gooseneck | Tilt Deck Tandem Axle | 5ft Stationary | Electric Brakes
20GTS 5ft SPECS↓
GVWR 25,000 lbs
Capacity (Distributed) 16,340 lbs
Base Trailer Weight 8,660 lbs
Frame Construction 8" x 4" Tubular Subframe with High Tensile Perimeter Rails
Crossmembers 4" x 2” Tubular Crossmembers on 16” Centers
Hitch 2-5/16” Gooseneck Coupler, 25,000 lb Capacity
Landing Gear 12,000 lb Capacity with Drop Foot
Safety Chains Qty 2 - 3/8" x 36" Grade 70 High Tensile Strength with Slip Hooks and Safety Latches
Deck Latch Over-Center Slider Shaft with Tension Adjuster and Safety Pin
Cushion Cylinder 4" x 16" with Metered Flow to Cushion Loading and Unloading
Load Securement 18 Each (9 per side) 2-way Chain Slot/Stake Pocket System | 14 Each (7 per side) 1" Diameter D-Rings
Tool Compartment In Upper Gooseneck with Lockable Lid
Axles Qty 2 – 10,000 lb. Capacity
Hubs Oil Bath Type, 8 on 6.5" Bolt Circle with 5/8” Lug Nuts
Brakes 12-1/4" x 3-1/2" Electric Brakes both Axles with 12 Volt Sealed Breakaway System
Suspension 3-Point Spring with Axle Alignment Capability
Wheels 16" x 6" 8 on 6.5" Bolt Pattern
Tires ST235/85R16 Radial Load Range G
Finished Preparation Sandblast
Finish Coating 1 Stage Zink Based Paint
Electrical Phillips Sealed Harness System with Rubber Isolated LED Lighting
Decking 2” Rough Surface No.1 Grade Fir: Exterior Boards Fastened at all Crossmembers
Decking Width 102”
24GT
Gooseneck | Tilt Deck Tandem Axle | Electric Brakes
24GT SPECS↓
GVWR 30,000 lbs
Capacity (Distributed) 22,660 lbs
Base Trailer Weight 7,340 lbs
Frame Construction 8" x 4" Tubular Subframe with High Tensile Perimeter Rails
Crossmembers 4" x 2” Tubular Crossmembers on 16” Centers
Hitch 2-5/16” Gooseneck Coupler, 30,000 lb Capacity
Landing Gear 12,000 lb Capacity with Drop Foot
Safety Chains Qty 2 - 3/8" x 36" Grade 70 High Tensile Strength with Slip Hooks and Safety Latches
Deck Latch Over-Center Type with Tension Adjuster and Safety Pin
Cushion Cylinder 4" x 16" with Internal Metered Flow to Cushion Loading and Unloading
Load Securement 14 Each (7 per side) 2-way Chain Slot/Stake Pocket System | 10 Each (5 per side) 1" Diameter D-Rings
Tool Compartment In Upper Gooseneck with Lockable Lid
Axles Qty 2 – 12,000 lb Capacity
Hubs Oil Bath Type, 8 on 6.5" Bolt Circle with 5/8” Lug Nuts
Brakes 12-1/4" x 3-1/2" Electric Brakes both Axles with 12 Volt Sealed Breakaway System
Suspension 3-point Spring with Axle Alignment Capability
Wheels 16" x 6" 8 on 6.5" Bolt Pattern
Tires ST235/85R16 Radial Load Range G
Finished Preparation Sandblast
Finish Coating 1 Stage Zink Based Paint
Electrical Philips Sealed Harness System with Rubber Isolated LED Lighting
Decking 2” Rough Surface No.1 Grade Fir: Exterior Boards Fastened at every other Crossmember, Interior Boards Fastened at every other Crossmember
Decking Width 102”
24GTS
Gooseneck | Tilt Deck Tandem Axle | 5ft Stationary | Electric Brakes
24GTS 5ft SPECS↓
GVWR 30,000 lbs
Capacity (Distributed) 21,340 lbs
Base Trailer Weight 8,660 lbs
Frame Construction 8" x 4" Tubular Subframe with High Tensile Perimeter rails
Crossmembers 4" x 2” Tubular Crossmembers on 16” Centers
Hitch 2 - 5/16” Gooseneck Coupler, 30,000 lb Capacity
Landing Gear 12,000 lb Capacity with Drop Foot
Safety Chains Qty 2 - 3/8" x 36" Grade 70 High Tensile Strength with Slip Hooks and Safety Latches
Deck Latch Over-Center Slider Shaft Latch with Tension Adjuster and Safety Pin
Cushion Cylinder 4" x 16" with Metered Flow to Cushion Loading and Unloading
Load Securement 18 Each (9 per side) 2-way Chain Slot/Stake Pocket System | 14 Each (7 per side) 1" Diameter D-Rings
Tool Compartment In Upper Gooseneck with Lockable Lid
Axles Qty 2 – 12,000 lb Capacity
Hubs Oil Bath Type, 8 on 6.5" Bolt Circle with 5/8” Lug Nuts
Brakes 12-1/4" x 3-1/2" Electric Brakes both Axles with 12 Volt Sealed Breakaway System
Suspension 3-Point Spring with Axle Alignment Capability
Wheels 16" x 6" 8 on 6.5" Bolt Pattern
Tires ST235/85R16 Radial Load Range G
Finished Preparation Sandblast
Finish Coating 1 Stage Zink Based Paint
Electrical Philips Sealed Harness System with Rubber Isolated LED Lighting
Decking 2” Rough Surface No.1 Grade Fir: Exterior Boards Fastened at every other Crossmember, Interior Boards Fastened at every other Crossmember
Decking Width 102”
30GTS
Gooseneck | 5’ Stationary | 26’ Tilt Deck
30GTS SPECS↓
GVWR 40,000 lbs
Capacity (Distributed) 30,500 lbs
Base Trailer Weight 9,460 lbs
Frame Construction 8" x 4" Tubular Subframe with High Tensile Perimeter rails
Crossmembers 4" x 2” Tubular Crossmembers on 16” Centers
Hitch 3” Gooseneck Coupler, 40,000 lb Capacity
Landing Gear 12,000 lb Capacity with Drop Foot
Safety Chains Qty 2 - 3/8" x 36" Grade 70 High Tensile Strength with Slip Hooks and Safety Latches
Deck Latch Over-Center Slider Shaft Latch with Tension Adjuster and Safety Pin
Cushion Cylinder 4" x 16" with Metered Flow to Cushion Loading and Unloading
Load Securement 18 Each (9 per side) 2-way Chain Slot/Stake Pocket System | 14 Each (7 per side) 1" Diameter D-Rings
Tool Compartment In Upper Gooseneck with Lockable Lid
Axles Qty 2 – 16,000 lb Capacity
Hubs Oil Bath Type, 8 on 275mm Bolt Circle with M22 Lug Nuts
Brakes 12-1/4" x 5" Electric Brakes both Axles with 12 Volt Sealed Breakaway System
Suspension 3-Point Spring with Axle Alignment Capability
Wheels 17.5" x 6.75" 8 on 275mm Bolt Pattern
Tires ST215/75R 17.5 Radial Load Range H
Finished Preparation Sandblast
Finish Coating 1 Stage Zinc Based Paint
Electrical Philips Sealed Harness System with Rubber Isolated LED Lighting
Decking 2” Rough Surface No.1 Grade Fir: Exterior Boards Fastened at all Crossmembers, Interior Boards Fastened at every other Crossmember
Decking Width 102”
