20BR Specs↓

GVWR 26,000

Capacity (Distributed) 20,180 lbs

Base Trailer Weight 5,820 lbs

Frame Construction 8" x 4" Tubular Subframe with High Tensile Perimeter Rails

Crossmembers 4” x 2" Tubular Crossmembers on 16” Centers

Hitch 2.5" Lunette Eye, 60,000 lb. Capacity, Adjustable Height

Landing Gear 10,000 lb. Capacity with Drop Foot

Safety Chains Qty 2 - 3/8" x 36" Grade 70 High Tensile Strength Plated with Slip Hooks and Safety Latches

Ramps Double Hinged Spring Assisted, 56" x 24"

Load Securement 12 each (6 per side) 2-way Chain Slot/Stake Pocket System

Tool Compartment Combination Open Tool Tray and Lockable Lid

Axles QTY 2 – 10,000 lb. Capacity

Hubs 8 on 6.5" Bolt Circle with 5/8" Lug Nuts

Brakes 12" x 2" Electrical Brakes, both Axles with 12-Volt Sealed Breakaway System

Suspension 3-Point Slipper Spring

Wheels 16" x 6" 8 on 6.5" Bolt Pattern

Tires 235/85R 16 Radial Load Range G

Finished Preparation Sandblast

Finish Coating 1 Stage Zink Based Paint

Electrical Phillips Sealed Harness System with Rubber Isolated LED Lighting

Decking 2" Rough Surface No.1 Grade Fir with Fasteners at every other Crossmembers

Decking Width 102"

24BR Specs↓

GVWR 31,200

Capacity (Distributed) 25,380 lbs

Base Trailer Weight 5,820 lbs

Frame Construction 8" x 4" Tubular Subframe with High Tensile Perimeter Rails

Crossmembers 4” x 2" Tubular Crossmembers on 16” Centers

Hitch 2-1/2" Lunette Eye, 60,000 lb Capacity Adjustable

Landing Gear 12,000 lb Capacity with Drop Foot

Safety Chains Qty 2 - 3/8" x 36" Grade 70 High Tensile Strength Plated with Slip Hooks and Safety Latches

Ramps Double Hinged Spring Assisted, 56" x 24" (L x W)

Load Securement 12 each (6 per side) 2-way Chain Slot/Stake Pocket System

Tool Compartment Combination Open Tool Tray and Lockable Toolbox

Axles Qty 2, 12,000 lb Capacity

Hubs 8 on 6.5" Bolt Circle with 5/8" Lug Nuts

Brakes 12" x 2" Electrical Brakes, both Axles with 12-Volt Sealed Breakaway System

Suspension 3-Point Slipper Spring

Wheels 16” x 6” 8 on 6.5" Bolt Circle

Tires 235/85R 16 Radial Load Range G

Finished Preparation Sandblast

Finish Coating 1 Stage Zink Based Paint

Electrical Phillips Sealed Harness System with Rubber Isolated LED Lighting

Decking 2" Rough Surface No.1 Grade Fir with Fasteners at every other Crossmember

Decking Width 102"

40BR Specs↓

GVWR 48,960 lbs

Capacity (Distributed) 40,000 lbs

Base Trailer Weight 8,960 lbs

Frame Construction Tubular Subframe with High Tensile Strength Perimeter Rails

Crossmembers 5" Tubular Crossmembers on 12" and 16" Centers

Hitch 3" ID Lunette Eye, 90,000 lb. Capacity Adjustable Height

Landing Gear 35,000 lb. Capacity with Drop Foot

Safety Chains Qty 2 - 1/2" x 36" Grade 70 High Tensile Strength with Slip Hooks and Safety Latches

Ramps Double Hinged Spring Assisted, 56" x 24"

Load Securement 12 each (6 per side) 2-way Chain Slot/Stake Pocket System

Tool Compartment Combination Open Tool Tray and Lockable Toolbox

Axles Qty 2 - 25,000 lb. Capacity

Hubs Oil Bath Type 8 on 275mm Bolt Circle with M22 Lug Nuts

Brakes 12-1/4" x 7-1/2" S-CAM Full Air Brakes with Maxi Spring Brakes on both Axles, Automatic Slack Adjusters, Equipped with 2S/2M ABS

Drums Steel Outboard Type

Suspension Hutch H-9700 Tandem-Axle with Fabricated Hangers and Axle Alignment Capability

Wheels 17.5” x 6.75” Uni-mount 8 on 275mm Bolt Pattern

Tires 215/75R 17.5 Radial Load Range H

Finished Preparation Sandblast

Finish Coating 1 Stage Zinc Based Paint

Electrical Phillips Sealed Harness System with Rubber Isolated LED Lighting

Decking 2" Rough Surface No.1 Grade Fir with Fasteners at every other Crossmember

Decking Width 102"

54BR Specs↓

GVWR 66,800 lbs

Capacity (Distributed) 54,080 lbs

Base Trailer Weight 12,720 lbs

Frame Construction Tubular Subframe with High Tensile Strength Perimeter Rails

Crossmembers 5" Tubular Crossmembers on 12" and 16" Centers

Hitch 3" ID Lunette Eye, 90,000 lb. Capacity, Adjustable Height

Landing Gear 35,000 lb. Capacity with Drop Foot

Safety Chains Qty 2 - 1/2" x 36" Grade 70 High Tensile Strength with Slip Hooks and Safety Latches

Ramps Double Hinged Spring Assisted, 56" x 24"

Load Securement 20 each (10 per side) 2-way Chain Slot/Stake Pocket System

Tool Compartment Combination Open Tool Tray and Lockable Toolbox

Axles Qty 3 - 25,000 lb. Capacity

Hubs Oil Bath Type, 8 on 275mm Bolt Circle with M22 Lug Nuts

Brakes 12-1/4" x 7-1/2" S-CAM Full Air Brakes with Maxi Spring Brakes on one Axle, Automatic Slack Adjusters, 2S/2M ABS

Drums Steel Outboard Type

Suspension Hutch H-9700 Tri-Axle with Fabricated Hangers and Axle Alignment Capability

Wheels 17.5” x 6.75” Uni-mount 8 on 275mm Bolt Pattern

Tires 215/75R 17.5 Load Range H

Finished Preparation Sandblast

Finish Coating 1 Stage Zinc Based Paint

Electrical Phillips Sealed Harness System with Rubber Isolated LED Lighting

Decking 2" Rough Surface No.1 Grade Fir with Fasteners at every other Crossmember

Decking Width 102"
